It's not just the right choice. It's the best choice.
Wayne-Dalton Rolling Doors have a long history of excellence in the design and construction of doors that have met and often exceeded the needs and expectations of even the most critical projects.
With numerous innovations created and experience acquired over the years, Wayne-Dalton continues to lead all other manufacturers with both standard and custom-made doors from a variety of materials and colors to meet almost any need.
So whether it's enormous Titan rolling doors, protective FireStar rolling steel fire doors, ventilated Secur-Vent doors, or secure Accordian-Folding Grilles, you can feel confident that with Wayne-Dalton's many years of knowledge and experience, you will get the best possible solution for your building application needs.
Guide to Rolling Doors
Choosing the right rolling door for a specific application can seem like a challenge, but it doesnt have to be. The following chart should help you narrow down your search to a few relevant door models.
ROLLING DOORS | Max Width | Max Height | Fire Labeled | Windload Rated | Construction | Available Gauges |
---|---|---|---|---|---|---|
Model 900 Service Door | 16' 0" | 16' 0" | – | 20-31 PSF | Steel, Aluminum, Stainless Steel | 20, 22, 24 |
Model 926 Service Door | 12' 0" | 12' 0" | – | 20 PSF | Galvanized Steel | 26 |
Model 800 Service Door | 42' 0" | 40' 0" | – | 20-55 PSF | Steel, Aluminum, Stainless Steel | 16, 18, 20, 22 |
Model 800C Service Door (insulated) | 42' 0" | 40' 0" | – | 20-55 PSF | Steel, Aluminum, Stainless Steel | 18, 20, 22 |
Titan Steel Service Doors | 70' 0" | 90' 0" | – | 20 PSF | Steel | 14, 18 |
FireStar 700 Rolling Steel Fire Door | 32' 2" | 24' 0" | Yes | N/A | Steel, Stainless Steel | 18, 20, 22 |
FireStar 700C Insulated Rolling Steel Fire Door | 24' 0" | 24' 0" | Yes | N/A | Steel, Stainless Steel | 18, 20, 22 |
Model 600 Rolling Grille | 42' 0" | 26' 0" | – | N/A | Steel, Aluminum, Stainless Steel | N/A |
Model 600 EES Emergency Egress Grille | 24' 0" | 20' 0" | – | N/A | Steel, Aluminum, Stainless Steel | N/A |
Atler Fire Shutter | 16' 0" | 8' 0" | Yes | N/A | Steel, Stainless Steel | 20, 22 |
Rolling Counter Shutter | 20' 0" | 8' 0" | – | N/A | Steel, Aluminum, Stainless Steel | 20, 22 |
Wood Counter Shutter | 14' 0" | 7' 0" | – | N/A | Various Woods | N/A |
Accordion-Folding Grille | 50' 0" | 10' 0" | – | N/A | Steel, Aluminum | N/A |
Integral Frame Counter Shutter | 14' 0" | 7' 0" | Optional | N/A | Steel, Aluminum, Stainless Steel | 20, 22 |
Secur-Vent® Ventilated Service Door | 22' 0" | 20' 0" | – | 20 PSF | Steel, Aluminum, Stainless Steel | 20, 22 |
SELF STORAGE DOORS | Max Width | Max Height | Locking | Construction | Construction |
---|---|---|---|---|---|
DS-357 Roll-Up Door | 16' 0" | 16' 0" | Slide Bolt or Curtain Lock | 26 Gauge Steel | 150 MPH |
DS-350 Roll-Up Door | 16' 0" | 16' 0" | Slide Bolt or Curtain Lock | 26 Gauge Steel | - |
DS-200 Roll-Up Door | 16' 0" | 16' 0" | Slide Bolt or Curtain Lock | 26 Gauge Steel | - |
